Technical Specifications
Issue V1.0 (2018-05-11)
85
5 Technical Specifications
Table 5-1 lists the technical specifications of the camera.
Table 5-1 Technical specifications
Specifications
0E-21D28WDR
0E-21BF36WDR
CAMERA
Image Sensor
1/2.7” Progressive Scan CMOS
Min. illumination
Color :0.2Lux@(F1.2,AGC ON)
B/W: 0 Lux@(IR LED ON)
Day & Night
ICR
Shutter Speed
1/5-1/20000
Auto Iris
Fixed
Wide Dynamic Range
WDR >120dB
Digital Noise Reduction
2D/3D
Lens
2.8mm
3.6mm
FOV
90°
85°
IR LED
18pcs
IR Range
30m
Video Compression
H.265/H.264/MJPEG
Bit Rate (CBR/VBR)
Main stream: 1080P: 500Kbps-12Mbps,
720P:200Kbps-8Mbps ;
Sub stream: 100kb-6000kb
Audio Compression
G.711 ,RAW_PCM
Max. Resolution
1920*1080/30fps
Stream
Stream 1 1920*1080 /1280*720
Stream 2 D1 to QVGA
Stream 3
1920*1080/1280*720/D1/VGA/640*360/CIF/QVGA
Image Setting
Rotate Mode, Saturation, Brightness, Contrast ,Sharpness
