WBOX Technologies 0E-13D28 - 1 Hardware Connection

Hardware Connection
High-Resolution IR Camera
User Manual
6
Issue V1.0 (2018-05-11)
1 Hardware Connection
Figure 1-1 shows the power and network cables.
Figure 1-1 Power and network cables
Table 1-1 shows the description of the cable.
Table 1-1 description of the cable
ID
Core
Description
1
Network access port
Connects to a standard Ethernet cable.
2
Power supply (DC 12V)
Connects to a 12V(-15%-+10% ) direct current
(DC) power supply.
