WBOX Technologies 0E-13D28 User Manual

High-Resolution IR Camera
User Manual
Web Operation
Issue V1.0 (2018-05-11)
57
Procedure
Step 1 Choose Configuration > Network Service > Port Mapping.
The Port Mapping page is displayed, as shown in Figure 4-29.
Figure 4-29 Port Mapping page
Step 2 Click the button on to enable Port Mapping.
Step 3 Set the parameters according to Table 4-17.
Table 4-17 Port mapping parameters
Parameter
Description
Setting
Port Mapping
Indicates whether to enable the
Port Mapping service.
[Setting method]
Click the button on.
[Default value]
OFF
Map Mode
Mode of port mapping, includes
auto and manual.
[[Setting method]
Select a value from the
drop-down list box.
[Default value]
Auto
Port Type
Port Type includes: HTTP, RTSP
and Control
N/A
