WBOX Technologies 0E-13D28 - Page 79

High-Resolution IR Camera
User Manual
Web Operation
Issue V1.0 (2018-05-11)
77
Figure 4-40 Multicast Param page
Table 4-28 Parameter description
Parameter
Description
Setting
Stream ID
ID of stream.
[Setting method]
Select a value from the drop-
list box.
[Default value]
1
IP
IP address that receive multicast data.
[Setting method]
Enter a value manually.
[Default value]
238.255.255.255
Video Port
Port that receive video data.
[Setting method]
Enter a value manually.
[Default value]
25330
Source Port
Port that receive source data.
[Setting method]
Enter a value manually.
[Default value]
25530
Step 2 Click Apply.
The message "Apply success, effective after restart!" is displayed, when the device
restarts, the system will save the settings.
----End
