7.6.8. Functional function at the buttom of monitor
① Indicates playback range of recorded image.
② Press button as the time set at (5) so as to change the time zone to playback
in forwarding and backwarding.
③ From left button, it can ‘Move a frame back’, ‘Play backward’, ‘Stop’, ‘Play’, ‘Move a
frame forward’.
④ It is the function to set play speed. After click the button, it can set the play speed ‘0.5x,
1x, 2x, 4x, 16x, 32x, 64x, and All’.
⑤ It is the function to set play area. After click the button, it can select play area ‘10min,
30min, 1hour, 3hour, 6hour, 12hour, 24hour’.
⑥ It can select DirectX use or not. If check DirectX mode, it can play image into Direct
Draw based on graphic card and performance of PC.
⑦ It is the function to set audio play or not, and volume.
