INSTALLATIONANDCONNECTION
3.2.3.1Pre-chargeCircuitControlFuses
FrameEcontainsthreefusestoprotectthecontrolcircuit,locatedontheFPC90Eboard.
ThelocationoftheFPC90EboardisshowninFigure3.11.
Incasereplacementisrequired,usecontrolfusesasspecifiedbeloworequivalent:
0.5A/600Vtime-delayfuse.
Manufacturer:CooperBussmann.
Commercialreference:FNQ-R-1/2.
WEGItem(materialnumber):10411493.
Figure3.11:Fusesforthecontrolcircuit
3.2.4PowerConnections
PE R S T
U
V W PE
W
V UPE
R
S
T
Shielding
Fuses
Disconnect Switch
PE
Figure3.12:Powerandgroundingconnections
