WEG CFW900 - Instructions for Computer Connection

English
FIRSTTIMEPOWER-UPANDSTART-UP
5.3INSTRUCTIONSFORCOMPUTERCONNECTION
✓
NOTE!
Always useshielded USB interconnect cable,“standardhost/device shieldedUSB cable”.
Unshieldedcablesmayleadtocommunicationerrors.
RecommendedcablesSamtec:
-USBC-AM-MB-B-B-S-1(1meter).
-USBC-AM-MB-B-B-S-2(2meters).
-USBC-AM-MB-B-B-S-3(3meters).
TheUSBconnectionisgalvanicallyisolatedfromthemainspowersupplyandfromotherhigh
voltagesinternaltotheinverter.However,theUSBconnectionisnotisolatedfromtheprotective
ground(PE).UseanisolatednotebookfortheUSBconnectionoradesktopconnectedtothesame
protectiveground(PE)oftheinverter.
TocontrolthemotorspeedandtoviewandprogramtheinverterthroughaPC,itisnecessarytoinstalltheWEG
WPSsoftware,availableat:
”www.weg.net”.
BasicproceduretotransferdatafromthePCtotheinverter:
1.InstalltheWEGWPSsoftwareonyourcomputer.
2.ConnectthePCtotheinverterviaUSBcable.
3.StarttheWEGWPS.
4.Select“File→ NewConfiguration”andfollowthestepsonthescreentomaketheconnection.
FormoredetailsandotherfunctionsrelatedtoWEGWPS,includingconnectionviaRS-485andEthernetinterfaces,
refertotheWEGWPSmanual.
CFW900|57
