TROUBLESHOOTINGANDMAINTENANCE
6.2PROTECTIONS,FAULTS,ALARMS,ANDPOSSIBLECAUSES
TheProtections,FaultsandAlarmsareafunctionalityoftheCFW900thatallowsviewingevents,helpingto
troubleshootandidentifyingimprovementsintheinverterparametersettings.
ProtectionsandfaultsdisablethemotorPWMpulses.ThereasonfortheiractuationisindicatedontheHMI,in
theCFW900statusword(S1.1.1)andinthecurrentprotectiondiagnosis(D1.1).Thisinformationisonly
clearedwitharesetorbyswitchingofftheinverter.
ThealarmsareindicatedontheHMI,intheCFW900statusword(S1.1.1)andinthecurrentalarmdiagnosis(
D2.1).Theyareautomaticallyclearedafterthealarmconditionceases.
TheProtections,FaultsandAlarmsarepresentedtotheuserthroughcodesprecededbythelettersFfor
protectionandfailureandAforalarm,asshownintheSection6.3.Inthissectionyoualsofindmoredetailsabout
thecausesandpossiblesolutions.
✓
NOTE!
Mostprotectionsandalarmscanbesolvedbyfollowingtheinstructionscontainedinthischapter;
otherwise,contactWEG’srepresentativeortechnicalsupport.
6.3PROTECTION,FAULTANDALARMTABLE
Protection/AlarmDescriptionPossiblecauses
F006:
GridUnbal./PhaseLoss
Unbalanceorphaselossinthepowersupply.
Note:
-Incasethemotorhasnoloadontheshaftorthe
loadislow,thisfaultmaynotoccur.
-ActuationtimesettoC7.1.1.WhenC7.1.1=0,the
faultisdisabled.
-Phaselossattheinverterinput.
-Inputvoltageunbalance>5%.
-Lossofonephaseinthepowersupply.
A010:
RectifierOvertemp.
Alarmofhightemperaturemeasuredinthe
temperaturesensors(NTC)oftherectifiermodules.
Note:
-ItcanbedisabledbychangingtheIGBTOvertemp.
settingtofaultonly,inparameterC7.5.1.
-Highambienttemperaturearoundtheinverter(>50
◦
C)andhighoutputcurrent.
-Lockedordefectivefan.
-Inverterheatsinktoodirty.
F011:
RectifierOvertemp.
Faultofovertemperaturemeasuredinthe
temperaturesensors(NTC)oftherectifiermodules.
-Highambienttemperaturearoundtheinverter(>50
◦
C)andhighoutputcurrent.
-Lockedordefectivefan.
-Inverterheatsinktoodirty.
A018:
LowBatteryVoltage
Lowbatteryvoltagealarm.-Replacethebattery.
A019:
24VdcPowerSupply
Overvoltage
24Vdcpowersupplyovervoltagefault.-Voltageofthe24Vdcpowersupplythatfeedsthe
controlabovethemaximumvalueof27.4Vcc.
A020:
24VdcPowerSupply
Undervoltage
24Vdcpowersupplyundervoltagefault.-Voltageofthe24Vdcpowersupplythatfeedsthe
controlbelowtheminimumvalueof22.8Vdc.
CFW900|59
