ACCESSORIES
7ACCESSORIES
7.1LISTOFACCESSORIES
Accessoriesishardwarethatcanbeaddedtotheinvertertoexpandtheproductapplicationpossibilities.Thus,all
modelsoftheCFW900linecanbeequippedwiththeaccessorieslistedinutandareinterchangeablebetweenall
frames,exceptfortheprotectionratingkits(ULtype1andIP21).
Table7.1:Accessoriesavailable
WEGItemNameDescription
ControlaccessoriesforinstallationinslotsAthroughG
(1)
Slots
taken
15691379CFW900-CCAN-W
(2)
CANinterfacemodule(CANopen/DeviceNet)
1
15691256CFW900-ENC-01
Moduleforconnectinganincrementalencoderwithasignalofupto310kHz
1
15691117CFW900-IOAI-01
Modulewith3analoginputsand2isolatedanalogoutputs
1
15691249CFW900-IOD-01
Modulewith8isolateddigitalinputsand8isolateddigitaloutputs
1
15691251CFW900-REL-01
Modulewith3digitalrelayoutputs(1unitsuppliedasstandard)
1
15691253CFW900-TEMP-01
Modulewith6isolatedinputsforPTC/PT100/PT1000sensors
1
IndividualHMI,frameandcablesforexternalHMI
15691113CFW900-HMI-BLTHMIwithBluetoothinterface(Individualitem)(standardforoptionB)
(3)
15690771CFW900-HMIHMI(Individual)
(3)
15756246CFW900-RHMIFFramekitforremoteHMI(IP65/ULType12protectionrating)
15692985CFW900-CCHMIR01MSerialcableforremoteHMI1m
15693038CFW900-CCHMIR02MSerialcableforremoteHMI2m
15693040CFW900-CCHMIR03MSerialcableforremoteHMI3m
15693042CFW900-CCHMIR05MSerialcableforremoteHMI5m
15693044CFW900-CCHMIR07MSerialcableforremoteHMI7.5m
15693045CFW900-CCHMIR10MSerialcableforremoteHMI10m
Miscellaneous
15692737CFW900-4SLOTSBackplanewith4slots(AthroughD)toconnectaccessories(suppliedasstandard)
15692736CFW900-7SLOTSBackplanewith7slots(AthroughG)toconnectaccessories
15756311CFW900-KN1ANema1kitforframeA
(4)
15757498CFW900-KN1BNema1kitforframeB
(4)
15757502CFW900-KN1CNema1kitforframeC
(4)
15757538CFW900-KN1DNema1kitforframeD
(4)
15757540CFW900-KN1ENema1kitforframeE
(4)
16240897CFW900-IP21AIP21kitforframeA
(5)
16241128CFW900-IP21BIP21kitforframeB
(5)
16241129CFW900-IP21CIP21kitforframeC
(5)
16241130CFW900-IP21DIP21kitforframeD
(5)
15757541CFW900-IP21EIP21kitforframeE
(5)
16352814CFW900-SDC8GBindustrialtemperaturemicroSDcard
(1)
Controlaccessoriescanbeinstalledinanyavailableslot.Exceptforexplicitlylistedcases,upto7accessoriesofthesametypecanbe
used.
(2)
ItisonlypossibletouseoneCFW900-CCAN-Wcommunicationmoduleperinverter.
(3)
ForremoteHMIconnection,useaD-Sub9(DB-9)maleandfemalecablewithpin-to-pinconnections.MaximumlengthaccordingtoTable
8.10.
(4)
Formoredetailsseeitems8.4.8and8.4.9.
(5)
Formoredetailsseeitems
8.4.6and8.4.7.
Table7.2:Consumptionoftheaccessories
ModelConsumption(I
ACC,n
)
(1)
CFW900-CCAN-W0.00A
CFW900-ENC-010.20A
CFW900-IOAI-010.10A
CFW900-IOD-010.00A
CFW900-REL-010.05A
CFW900-TEMP-010.05A
(1)
“n”indicatestheslottowhichtheaccessorywill
beconnected.
