INSTALLATIONANDCONNECTION

Figure3.10:BRterminalprotectionforDClinksupply-frameC

3.2.2PowerandGroundingWiring

WARNING!

Whenpowerandgroundconnectionsaremadewithﬂexiblecables,itisnecessarytousesuitable

terminals.

WARNING!

Sensitiveequipment,suchasPLCs,temperaturecontrollersandthermocouplecables,shouldbeat

least0.25metersawayfromthefrequencyinvertersandcablesconnectingtheinvertertothemotor.

DANGER!

Wrongcableconnection:

Theinverterwillbedamagedincasetheinputpowersupplyisconnectedtotheoutputterminals

(U/T1,V/T2,orW/T3)

Checkalltheconnectionsbeforepoweringuptheinverter.

IncaseofreplacinganexistinginverterbyaCFW900,checkiftheinstallationandwiringisaccording

totheinstructionslistedinthismanual.

✓

NOTE!

ThewiregaugeslistedinTable3.4areorientativevalues.Installationconditionsandthemaximum

permittedvoltagedropmustbeconsideredfortheproperwiringsizing.

20|CFW900
