SSW7000 | 2-1
2 ABOUT THE MANUAL
This manual presents the necessary information for the installation and commissioning, as well as the product
main technical characteristics, and how to troubleshoot the SSW7000 most common problems.
This manual must be used together with the SSW7000 programming manual.
ATENÇÃO!
The operation of this equipment requires installation instructions and detailed operation provided in
the user's manual, programming manual and communication manuals. The user's manual and the
programming manual are supplied in a hard copy together with the soft-starter. The us
are also provided in a hard copy along with the accessories. The other manuals can be downloaded
from the WEG website at - www.weg.net.
In order to obtain more information on the accessories and its operation, refer to the following manuals:
RS-232/RS-485 Serial Communication Manual.
Anybus-CC Communication Manual.
SoftPLC Manual
Reproduction of this manual content is prohibited, as a whole or in parts, without written permission from WEG.
2.1. TERMS AND DEFINITIONS
2.1.1. Terms and Definitions Used in the Manual
Amp,
A:
ampere
AC:
alternating current.
DC:
direct current.
DOL:
Direct Online start.
°C:
c
e
l
s
i
us degrees
.
HMI
: Human-Machine Interface; it is the device that allows the control of the motor, the visualization and the
modification of the SSW7000 parameters. It presents keys for commanding the motor, navigation keys and a
graphic LCD display.
hp:
“Horse Power” = 746 Watts (power measurement unit, normally used to indicate the mechanical power of
electric motors).
Hz:
hertz.
kg:
kilogram
= 1000 gramas.
kHz:
kilohertz
= 1000 hertz.
kV:
kilovolts
= 1000
v
o
l
t
s
.
mA:
miliampere
= 0.001 ampères.
