WEG SSW7000 User Manual

SSW7000 | 6-2
Internal Connections
NOTE!
The SSW7000 CC11 hardware is identical to that of the CFW-11 CC11. However, the firmware
version and the PLD code are different. Because of the different PLD code, it is not possible to
transform a CFW-11 board into an SSW7000 one by
simply updating the firmware. Only the
CC11xy.Sz boards are adequate for the SSW7000. If an SSW7000 firmware version is flashed into
a board with a CFW-11 PLD, then the fault “Incompatible PLD Firmware” will appear on the display.
6.1.2. CSM Board Connections
Table 6.3: Description of the CSM2/CSM3 board connections
CSM2
Terminal Strip
Description
XC1 CSM2 Isolated supply
1 a 5 CT input, common points (red)
6 CT input (yellow)
XC2 CSM2 Isolated supply
1 a 6 Common points for the connections of the CTs (blue)
CSM3
Terminal Strip
Description
XC1 CSM3 Isolated supply
1 CT input (blue)
2 a 6 Common points for the connections of the CTs (red)
XC2 CSM3 Isolated supply
1 a 2 CT input (yellow)
3 a 6 Common points for the connections of the CTs (blue)
CSM2 / CSM3
Terminal Strip
Description
XC4 CT cable Current Reading
1 Red
CT - R-U arm current
2 Black
3 Red
CT –S-V arm current
4 Black
5 Red
CT – T-W arm current
6 Black
7 Red
CT – Ground fault
8 Black
Terminal Strip
Description
Optocouplers Power arm SCR firing and temperature reading
N27 to N32 R-U arm firing
N21 to N26 S-V arm SCR firing
N15 to N20 T-W arm SCR firing
N7 R-U arm temperature
N8 S-V arm temperature
N9 T-W arm temperature
CSM
FSMT
Connections between boards
N3 N3
Communication between the C1 and C2 control
boards through fiber optic cables
N4 N4
N5 N5
N11 N11
Current and voltage synchronism feedback
N12 N12
CSM3
CSMGA
Connections between boards
XC3 XC1 Communication between boards CSM3-CSMGA
