WEG SSW7000 - Auxiliary Low Voltage Supply Connection

SSW7000 | 5-34
Installation and Connection
5.2.11. Auxiliary Low Voltage Supply Connection
Check the electric project that accompanies the product, which must contain the indication of the connections,
including the power supply and the use of circuit breakers to protect the power supply circuit.
Components fed by the auxiliary power supply:
 The electronic board FSMT.
 The coils of the line and by-pass contactors.
 Auxiliary contactors used in the cabinet.
 Power arm fans (if used).
NOTE!
The auxiliary low voltage power supply value must match the electronics supply value specified in
the product code. Refer to the section 3.3 - How to Specify the SSW7000 Model (Smart Code).
