DTV 720 USER’S MANUAL
www.wegener.com 7 800043-01 Rev. C
Chapter 2 Installation
This chapter provides instructions on unpacking, mounting, and connecting the DTV 720,
as well as connector information including detailed pinouts.
2.1 Unpacking and Inspection
Carefully unpack the unit and its ac power cord and inspect for obvious signs of physical
damage that might have occurred during shipment. Any damage claims must be reported
to the carrier immediately. Be sure to check the package contents carefully for important
documents and materials.
NOTE: Please save the packing materials and original shipping containers in case you must later
return the unit for repair. Packing these units in other containers in such a way that they are
damaged will void your warranty.
2.2 Location and Mounting
The DTV 720 should be located indoors and may be mounted in a standard, 19-inch equip-
ment rack within one standard RU.
WARNING
This is a Class A product. In a domestic environment this product may cause radio
interference for which the user may need to take mitigating action.
DANGER
To avoid damage to this and other equipment, or personal injury, the following items
should be strictly observed.
Elevated Operating Ambient
When equipment is installed in a closed or multi-unit rack assembly, the operating ambient
of the rack environment may be greater than the room ambient. Therefore, consideration
should be given to the ambient air temperature within the rack, and not just inside the
room, when deciding if the maximum recommended ambient operating temperature
(T
MRA
) is being met or exceeded.
Reduced Air Flow
Equipment should be installed such that airflow required for safe operation of the equip-
ment is not compromised.
Mechanical Loading
Mounting of the equipment in a rack should be such that a hazardous condition is not pro-
duced by uneven loading. This unit is not very heavy, but total rack loading must be con-
sidered. Also, do not rest any unsupported equipment on your DTV 720.
