11Manual maxGUARD2526740000/02/03.2018
3 Systemoverview | Product overview
3.6 Product overview
maxGUARDcomponents–standardversion
The following maxGUARD products have uncoated PCBs and
standard certication (see section 3.9).
Product designation Function Order No.
Feed-in modules, control module, alarm module
AMG FIM-0 Feed-in module, passive 2081870000
AMG FIM-C Feed-in module, active (reset, alarm) 2081880000
AMG CM Control module (reset, alarm, overload advance warning, ON/OFF) 2081900000
AMG AM Alarm module (alarm, overload advance warning), potential-free output contacts 2081890000
Electronic load monitors
AMG ELM-6 1-channel, adjustable: 1–6A 2080360000
AMG ELM-12 1-channel, adjustable: 4–12A 2080410000
AMG ELM-1F 1-channel, xed-value: 1A 2080420000
AMG ELM-2F 1-channel, xed-value: 2A 2080480000
AMG ELM-4F 1-channel, xed-value: 4A 2080490000
AMG ELM-6F 1-channel, xed-value: 6A 2080500000
AMG ELM-8F 1-channel, xed-value: 8A 2080600000
AMG ELM-10F 1-channel, xed-value: 10A 2080650000
AMG ELM-1F CL2 1-channel, xed-value: 1A, Class2 (UL1310) 2491270000
AMG ELM-2F CL2 1-channel, xed-value: 2A, Class2 (UL1310) 2491280000
AMG ELM-4F CL2 1-channel, xed-value: 4A, Class2 (UL1310) 2491290000
AMG ELM-Q2222 4-channel, xed-value: 2-2-2-2A 2080750000
AMG ELM-Q4444 4-channel, xed-value: 4-4-4-4A 2080880000
AMG ELM-Q6666 4-channel, xed-value: 6-6-6-6A 2080920000
AMG ELM-Q2244 4-channel, xed-value: 2-2-4-4A 2081650000
AMG ELM-Q2266 4-channel, xed-value: 2-2-6-6A 2081820000
Potential distribution terminals
AMG PD 4xplus (grouped) 2122920000
AMG OD 2xplus, 2xminus (alternating) 2122910000
AMG MD 4xminus (grouped) 2122930000
AMG XMD 4xminus, electrical connection to GND main strand 2122940000
AMG DIS Disconnecting lever for all-pole load separation 2123050000
