9 Operation | Resetting load monitors
9.3 Resetting load monitors
To avoid unexpected operational states, manu-
ally switched off load monitors ignore the reset
and ON/OFF signals. Manually switched off load
monitors can only be started up manually.
Manual resetting
You can reset individual tripped load monitors using the re-
set button “R”.
▶ While tripped, press the reset button “R” for 0.1 to 2sec-
onds.
The load monitor will switch off and the LED will illuminate
red.
▶ While switched off, press the reset button “R” for 0.1 to
2seconds.
The load monitor will switch to ready state and the LED will
illuminate green.
Resetting with a control unit
You can reset all tripped load monitors in a segment using
the reset signal. The segment must contain an AMGCM con-
trol module or an AMGFIM-C active feed-in module.
▶ To reset all load monitors in the segment, set the reset
input of the control module or the active feed-in module
to +24V for longer than 100 ms.
The reset LED or the ON/OFF LED will illuminate yellow. All
tripped load monitors will switch to ready state. The LEDs on
the load monitors will illuminate green.
9.4 Setting a new characteristic
▶ Turn the thumbwheel switch until the value for the
desired characteristic is visible in the window (see chap-
ter 6).
▶ Press the reset button “R” on the load monitor for 0.1 to
2seconds.
The load monitor will switch off and the LED will illuminate
red.
▶ While switched off, press the reset button “R” for 0.1 to
2seconds.
The load monitor will switch to ready state and the LED will
illuminate green. The new characteristic will now be active.
