Annex | Lagged tripping characteristic 8AT
PV
PV
PV
V
$$$
V
Output current
8.8 A < I ≤ 9.5 A 9.5 A < I ≤ 14 A 14 A < I ≤ 18 A 18 A < I ≤ 28 A 28 A < I ≤ 44 A I > 44 A
Tripping time
5s 1s 100ms 30ms 10ms 5ms
Lagged tripping characteristic 8A
T
