Weidmüller maxGUARD - Lagged Tripping Characteristic 12 A

A-20Manual maxGUARD2526740000/02/03.2018
Annex | Lagged tripping characteristic 12AT
PV
PV
PV
V
$$$
V
Output current
13.2 A < I ≤ 18 A 18 A < I ≤ 20 A 20 A < I ≤ 24 A 24 A < I ≤ 34 A 34 A < I ≤ 48 A I > 48 A
Tripping time
5s 1s 100ms 30ms 10ms 5ms
Lagged tripping characteristic 12A
T
