6 Electronicloadmonitors | AMGELM-xF...
Technical data AMGELM-1F... AMGELM-2F... AMGELM-4F... AMGELM-6F... AMGELM-8F... AMGELM-10F...
General
Rated voltage
24VDC
Operational voltage range
18–30VDC
Low voltage detection
Yes (supply voltage<18VDC)
Surge detection
Yes (supply voltage>31.2VDC)
Rated output current I
OUT,rated
1A 2A 4A 6A 8A 10A
Current consumption
I
OUT
+30mA
VoltagedropatI
OUT,rated
200mV
Capacitive load
10,000µF 15,000µF 20,000µF
Overtemperature protection
No
Width
6.1mm 12.2mm
Tripping behaviour
Adjustable
No
Tripping current I
T
1A 2A 4A 6A 8A 10A
Characteristics(normal)
1A
N
2A
N
4A
N
6A
N
8A
N
10A
N
Characteristics(delayed)
No
Bus decoupling, bus coupling
Alarm(tripped,fault)
Yes
Overload advance warning
(I>90%)
No
Reset
Yes
ON/OFF
Yes
Button function
Reset
Yes
ON/OFF
Yes
