Weidmüller maxGUARD - Normal Tripping Characteristic 4 A

A-5Manual maxGUARD2526740000/02/03.2018
Annex | Normal tripping characteristic 4AN
PV
PV
PV
V
$$$
V
Output current
4.4 A < I ≤ 5 A 5 A < I ≤ 6 A 6 A < I ≤ 10 A 10 A < I ≤ 18 A I > 18 A
Tripping time
5s 1s 100ms 10ms 5ms
Normal tripping characteristic 4A
N
