Weidmüller maxGUARD - Normal Tripping Characteristic 10 A

A-8Manual maxGUARD2526740000/02/03.2018
Annex | Normal tripping characteristic 10AN
PV
PV
PV
V
$$$
V
Output current
11 A < I ≤ 14 A 14 A < I ≤ 18 A 18 A < I ≤ 20 A 20 A < I ≤ 40 A I > 40 A
Tripping time
5s 1s 100ms 10ms 5ms
Normal tripping characteristic 10A
N
