41Manual maxGUARD2526740000/02/03.2018
6 Electronicloadmonitors | AMGELM-Qxxxx
Technical data AMGELMQ2222 AMGELMQ4444 AMGELMQ6666 AMGELMQ2244 AMGELMQ2266
General
Rated voltage
24VDC
Operational voltage range
18–30VDC
Low voltage detection
Yes (supply voltage<18VDC)
Surge detection
Yes (supply voltage>31.2VDC)
Rated output current I
OUT,rated
4x2A 4x4A 4x6A 2x2A+2x4A 2x2A+2x6A
Current consumption
I
OUT
+4x30mA
VoltagedropatI
OUT,rated
200mV
Capacitive load
10,000 µF per channel 15,000µF per channel 10,000 µF per channel
10,000 µF per 2A channel
15,000 µF per 6A channel
Overtemperature protection
Yes, per channel
Width
24.4mm
Tripping behaviour
Adjustable
No
Tripping current I
T
2A 4A 6A 2A, 4A 2A, 6A
Characteristics(normal)
2A
N
4A
N
6A
N
2A
N
, 4A
N
2A
N
, 6A
N
Characteristics(delayed)
No
Bus decoupling, bus coupling
Alarm(tripped,fault)
Yes
Overload advance warning
No
Reset
Yes
ON/OFF
Yes
Button function
Reset
Yes, per channel
ON/OFF
Yes, per channel
