6 Electronicloadmonitors | AMG ELM-xD C0
Technical data AMG ELM-6D C0 AMG ELM-10D C0
General
Rated voltage
24VDC
Operational voltage range
18–30VDC
Low voltage detection
Yes (supply voltage<18VDC)
Surge detection
Yes (supply voltage>31.2VDC)
Rated output current I
OUT,rated
6A 10A
Current consumption
I
OUT
+50mA
VoltagedropatI
OUT,rated
200mV 250mV
Capacitive load
15,000 µF 20,000 µF
Overtemperature protection
Yes
Width
18.3mm
Tripping characteristic
Adjustable
Yes
Tripping current I
T
1A, 2A, 3A, 4A, 6A 4A, 6A, 8A, 10A
Characteristics(normal)
1A
N
, 2A
N
, 3A
N
, 4A
N
, 6A
N
4A
N
, 6A
N
, 8A
N
, 10A
N
Characteristics(delayed)
1A
T
, 2A
T
, 3A
T
, 4A
T
, 6A
T
4A
T
, 6A
T
, 8A
T
, 10A
T
Bus decoupling, bus coupling
Alarm(tripped,fault)
Yes
Overload advance warning
Yes
Reset
Yes
ON/OFF
Yes
Button function
Reset
Yes
ON/OFF
Yes
Relay outputs
Contact type
NO contact
Galvanic isolation
All poles, functional
