1.2.2.2 Machine Control Area
This area consists of the following:
• Coordinate display area: used to show current active workpiece coordinate
system, workpiece coordinate and machine coordinate of each axis.
• Feed setting area: used to set feedrate override, modify setting speed and check
actual speed.
• Cycle setting area: used to set cycle times and interval, reset workpiece count
and check machining statistics.
• Tool and machining mode selecting area: used to select the tool(s), show and
reset the machining mode.
1.2.2.3 Mode Control Area
This area consists of the following modes:
• Auto mode
Used to show the loaded tool path file in details.
• Manual mode
Used to show axis direction buttons and mode buttons.
See Axis Direction and Mode Selecting Area for details.
• Reference mode
Used to execute the following operations related to returning to the machine
origin:
– Select whether to return to the machine origin when software starts.
– Set the direction during returning to the machine origin.
– Set the positioning speed during returning to the machine origin.
1.2.2.4 Function Control Area
This area is used to do the following:
• Execute common operations, including returning to the machine origin,
returning to the loading point and executing analog machining.
• Execute jiggle.
• Turn on/off common ports, including water valve, abrasive valve, oil pump,
high pressure valve and lube.
In Manual mode, there is no such area.
