Weiler E1650 - Fuses and Relays Check; Generator Adjustments and Tests

WEILER E1650 REMIXING TRANSFER VEHICLE
5-29
Maintenance
5
Maintenance Procedures
Fuses / Relays - Check
(1) Starter Relay
(2) Spray Down Relay
(3) Main Power Relay #1
(4) Main Power Relay #2
(5) Glow Plugs Relay
Generator - Adjust
1. Adjust hydraulic flow to generator drive motor with
flow control valve (1) to adjust generator speed for
an output frequency of 60 Hz.
A
2
3
4
5
6
7
8
9
10
1
