WEILER E1650 REMIXING TRANSFER VEHICLE
2-6
Machine Controls
2
Machine Controls
(10) Hopper Baffle Open Button
Press and hold to open hopper baffle.
(11) Hopper Baffle Close Button
Press and hold to close hopper baffle.
(12) Chain Spray Down Button
Press to turn on chain spray cycle.
Cycle can be adjusted using Electronic Display.
(13) Tire Spray Down Button
Press and hold to cycle tire spray down on/off.
Press and release to increase and decrease.
(14) Engine Start Button
With Ignition Switch in run position, press to start engine.
(15) Engine Speed Button
Press and release to cycle low, medium, and high engine rpm.
High engine rpm.
Medium engine rpm.
Low engine rpm.
10
11
13
15
14
12
