WEILER E1650 REMIXING TRANSFER VEHICLE
2-20
Machine Controls
2
Machine Controls
(5) Engine ECM / Machine Control
Communication Port
(6) Engine Stop Button
(7) Limp Mode Enable Button
Press and hold to enable Limp Mode Steering and
Ground Drive Switches.
(8) Limp Mode Steering Switch
(9) Limp Mode Ground Drive Switch
Press to stop engine quickly.
Pull to enable engine startup.
Push left to steer machine left.
Push right to steer machine right.
Push up to move machine forward.
Push down to move machine in reverse.
