WEILER E1650 REMIXING TRANSFER VEHICLE
2-21
Machine Controls
2
Machine Controls
Electronic Display Navigation
Menu Screen
View engine Diagnostics
View Drive Diagnostics
View Elevator/Storage Diagnostics
View Sensor Diagnostics
View CAN Diagnostics
System Settings
View Errors
Exit Enter
View Engine Diagnostics
Stop Button
Exit Page 1 of 2
Throttle Switch
Hydraulic Oil Temp.
Boost Pressure
Oil Pressure
Fuel Sensor Signal
Fuel Level
Fuel Pressure
Coolant Temp.
Percent Load
Engine Speed
Off
Unknown
170 ° F
1000 kPa
100 PSI
525 mV
65 %
55 PSI
210 ° F
100 %
1111 RPM
View Engine Diagnostics
Exit Page 2 of 2
DPF Soot Load
DEF Tank Temp.
DEF Level
Fuel Rail Pressure
Ambient Temp.
Generator
Battery
Engine Hours
42 %
100 ° F
85 %
10000 PSI
50 ° F
Off
12.0 VDC
150 Hours
Gauge Data
Elevator Storage Discharge
6001 5633 4578
PSIPSIPSI
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
PSI x1000 PSI x1000 PSI x1000
Distance To Paver
Set Distance: 1.0 FT
Actual Distance: 2.0 FT
Exit
%
DEF
1801 55 24.0
0125112
RPM Load VDC
PSI ° F FPM
Gauge
Data
Menu
15.0 Hours
05:35 PM 11/20/2016
E1650
View Sensor Diagnostics
Exit Page 1 of 3
Sonic Sensor
Sonic Distance
Hopper Insert Sonic Settings
10 mV
10.0 Inches
5.0 Inches
View Sensor Diagnostics
Exit Page 2 of 3
Radar Distance
Radar Voltage
Distance Control Active
Distance Control Switch
Set Distance
5.0 Feet
100 mV
Off
Off
1.0 Feet
Distance Control
Distance Control Light Off
View Sensor Diagonostic
Exit Page 3 of 3
Sonic Sensor
Sonic Distance
Storage Hopper (SHMS)
10 mV
10.0 Inches
127 mm
View Drive Diagnostics
Exit Page 1 of 2
Diff Lock
Park brake
Two Speed Coil
Start Relay
Propel Mode Switch
Propel Knob
Propel Level Position
Ground Drive Pump
Off
Off
Off
Off
Unknown
10000 #
255 mV
- 0 #
Forward 1200 mA
Reverse 0 mA
View Drive Diagnostics
Exit Page 2 of 2
Steering Actual Position
Steering Target Position
RH Steering Valve Output
LH Steering Valve Output
Steering Wheel Duty #2
Steering Wheel Duty #1
45.3
°
45.3 °
0 mA
0 mA
99.00 %
405.00 %
Front Steering
View Elevator/Storage Diagnostics
Exit Page 1 of 2
Discharge Pressure
Storage Pressure
Elevator Pressure
Discharge Output
Storage Output
Elevator Output
Storage/Discharge Knob
3000 PSI
200 PSI
1000 PSI
300 mA
200 mA
100 mA
111 #
10 mV
View Elevator/Storage Diagnostics
Exit Page 2 of 2
Auto Tension Cycles
Auto Tension
Warm-Up
Elevator Switch
Storage/Discharge Switch
10
Off
Not Complete
Off
Off
