Machine Controls
2
Machine Controls
Menu Screen Display
Use center control button to move box over selection of
screen to enter.
Press (1) to enter selected screen.
Press (2) to exit to previous screen.
View Engine Diagnostics Screens
Use center control button to scroll between engine
diagnostics screens.
(1) EXIT Button
Press EXIT button to exit to previous screen.
Menu Screen
View engine Diagnostics
View Drive Diagnostics
View Elevator/Storage Diagnostics
View Sensor Diagnostics
View CAN Diagnostics
System Settings
View Errors
Exit Enter
2
1
View Engine Diagnostics
Stop Button
Exit Page 1 of 2
Throttle Switch
Hydraulic Oil Temp.
Boost Pressure
Oil Pressure
Fuel Sensor Signal
Fuel Level
Fuel Pressure
Coolant Temp.
Percent Load
Engine Speed
Off
Unknown
170 ° F
1000 kPa
100 PSI
525 mV
65 %
55 PSI
210 ° F
100 %
1111 RPM
1
View Engine Diagnostics
Exit Page 2 of 2
DPF Soot Load
DEF Tank Temp.
DEF Level
Fuel Rail Pressure
Ambient Temp.
Generator
Battery
Engine Hours
42 %
100 ° F
85 %
10000 PSI
50 ° F
Off
12.0 VDC
150 Hours
