WEILER E1650 REMIXING TRANSFER VEHICLE
2-26
Machine Controls
2
Machine Controls
View Drive Diagnostics Screens
Use center control button to scroll between diagnostics
screens.
(1) EXIT Button
Press EXIT button to exit to previous screen.
View Elevator/Storage/Discharge Diagnostics Screens
Use center control button to scroll between elevator
diagnostics screens.
(1) EXIT Button
Press EXIT button to exit to previous screen.
View Drive Diagnostics
Exit Page 1 of 2
Diff Lock
Park brake
Two Speed Coil
Start Relay
Propel Mode Switch
Propel Knob
Propel Level Position
Ground Drive Pump
Off
Off
Off
Off
Unknown
10000 #
255 mV
- 0 #
Forward 1200 mA
Reverse 0 mA
1
View Drive Diagnostics
Exit Page 2 of 2
Steering Actual Position
Steering Target Position
RH Steering Valve Output
LH Steering Valve Output
Steering Wheel Duty #2
Steering Wheel Duty #1
45.3°
45.3°
0 mA
0 mA
99.00 %
405.00 %
Front Steering
1
View Elevator/Storage Diagnostics
Exit Page 1 of 2
Discharge Pressure
Storage Pressure
Elevator Pressure
Discharge Output
Storage Output
Elevator Output
Storage/Discharge Knob
3000 PSI
200 PSI
1000 PSI
300 mA
200 mA
100 mA
111 #
10 mV
1
View Elevator/Storage Diagnostics
Exit Page 2 of 2
Auto Tension Cycles
Auto Tension
Warm-Up
Elevator Switch
Storage/Discharge Switch
10
Off
Not Complete
Off
Off
1
