4-13
Remove Bellows
Retaining Clamp
d) Remove the bellows retaining clamp
from around the bellows.
e) Pull the bellows off the front of the
tub.
Remove Bellows
REASSEMBLY NOTE: When you reinstall the
bellows, be sure to position the “weep holes”
at the bottom, as shown below.
Bellows Weep Holes
To Next Page
