WinGD W-X82 User Manual

Operation0250−2/A1
Winterthur Gas & Diesel Ltd.
2/ 4
Media Unit Location Signal No.
(1)
Func-
tion
(2)
Type of
signal
(3)
Setting
value
[bar or _C]
Time
Interval
[sec]
Turbocharger oil Pressure Inlet PT2611−12A ALM L 1.0 bar 5
(ABB, A100-L type) SLD L 0.8 bar 60
PS2611−12S SHD L 0.6 bar 5
Temperature Housing outlet TE2601−02A ALM H
110_C
0
SLD H
120_C
60
Pressure Inlet PT2611−12A ALM L 1.3 bar 5
(with external SLD L 1.1 bar 60
oil supply) PS2611−12S SHD L 0.9 bar 5
Temperature Housing outlet TE2601−02A ALM H
130_C
0
SLD H
140_C
60
Additional requirement with external Inlet TE2621A ALM H
85_C
0
oil supply SLD H
90_C
60
Turbocharger oil Pressure Inlet PT2611−12A ALM L 0.7 bar 5
(MHI, MET type) SLD L 0.6 bar 60
PS2611−12S SHD L 0.4 bar 5
Temperature Housing outlet TE2601−02A ALM H
85_C
0
SLD H
90_C
60
Additional requirement with external Inlet TE2621A ALM H
60_C
0
oil supply SLD H
65_C
60
Turbocharger overspeed Speed TC casing ST5201−02A ALM H −
14)
0
Torsional vibration damper oil
(steel spring damper)
5)
Pressure Damper inlet PT2711A ALM L 2.2 bar
15)
0
Axial vibration damper oil Pressure Chamber aft side PT2721A ALM L 1.7 bar 60
Chamber fore side PT2722A ALM L 1.7 bar 60
Cylinder lubricating oil Diff. pressure Filter PS3121A ALM H 0.5 bar 0
Fuel oil Temperature
4)
before supply unit TE3411A ALM H
50_C to
160_C
0
(see Viscosity-Temperature
Diagram 0710−1)
ALM L
20 _C to
130_C
0
Pressure before supply unit PT3421A ALM L 7 bar 0
Viscosity
4)
before supply unit
5)
ALM H 17 cSt 0
ALM L 13 cSt 0
Temperature Fuel pump TE3431−36A ALM D
−30_C
12)
30
Outlet
Fuel leakage monitoring Level Supply unit
7)
LS3426−27A ALM H max. 0
Rail unit
7)
LS3444−45A ALM H max. 0
Fuel pipe
7)
LS3446−47A ALM H max. 0
Exhaust gas Temperature after each cylinder TE3701−09A ALM H
515_C
0
10)
ALM D
±50_C
0
SLD H
530_C
60
SLD D
±70_C
60
before TC
6)
TE3721−22A ALM H
515_C
0
10)
SLD H
530_C
60
after TC
6)
TE3731−32A ALM H
480_C
0
10)
SLD H
500_C
60
Scavenge air Temperature Scavenge air TE4031−32A ALM L
25_C
0
receiver after cooler ALM H
60_C
0
SLD H
70_C
60
Temperature each piston
underside
TE4081−89A ALM H
80_C
0
(fire detection) SLD H
120_C
60
2017−04
Alarms and Safeguards at Continuous Service Power
