5�2 Assembly and set-up
5�2�1 Installing the handlebars
4 mm
Unscrew the clamp bolts on the front of the stem. Place the handlebars in the stem.
The gear cable and brake hoses must both run along the left side of the head tube.
4 mm
1
4
3
2
Replace the clamps and slightly tighten
the bolts. Check that the cross mark is
centered between the two clamps.
Adjust the angle of the handlebars to
suit the rider. Your child should be able
to reach the bars easily while sitting on
the saddle and leaning forward a bit
with slightly bent arms.
Tighten the clamp bolts alternately
diagonally and keep going until the re-
quired torque is reached (see chapter 8).
Make sure that the handlebars cannot
be rotated when the bolts are tightened.
