wtw Multi 3620 IDS User Manual

Transmitting data Multi 3620 IDS
99 ba77169e01 04/2016
13.6 Data transmission to the USB-A interface (USB memory
device)
Via the USB-A interface, you can transmit data to a USB printer or USB mem-
ory device. How to transmit data to a USB memory device is described in an
extra section (see section 13.5).
The following table shows which data are transmitted to the interface in which
way:
Data Control Operation / description
Current
measured
values of all
connected
sensors
Manual  press
 Simultaneously with every manual
storing process (see section 12.1).
Automatic, at
intervals
 With <PRT__>.
Then you can set the transmission
interval
 Simultaneously with every automatic
storing process (see section 12.2).
Stored mea-
sured values
Manual  Displayed dataset with after call-up
from the storage.
 All datasets with the Output to RS232/
USB function (USB-B interface)
 All datasets with the Output to USB
flash drive or printer function (USB-A
interface)
For details, see section 12.3.1.
Calibration
records
Manual  Displayed calibration record with .
 All calibration records with <PRT__>.
For details, see section 13.
Automatic  At the end of a calibration procedure
The following rule applies: With the exception of the menus, shortly
pressing the key generally outputs the display contents to the inter-
face (displayed measured values, measuring datasets, calibration
records). If there is a USB-B connection (e.g. to a PC), the data are
output to the USB-B interface only.
Data Control Operation / description
Stored mea-
sured values
Manual All datasets with the Output to RS232/
USB function.
For details, see section 12.3.1
