Transmitting data Multi 3620 IDS
97 ba77169e01 04/2016
13 Transmitting data
13.1 Outputting current measurement data
13.2 Transmitting data
The meter has the following interfaces:
USB-B interface (USB Device)
e.g. to connect a PC
USB-A interface (USB Host),
e.g. to connect a USB flash drive/USB printer
Via the USB-B interface (USB Device) you can transmit data to a PC or printer
and update the meter software.
Via the USB-A interface (USB Host) it is possible to transfer data to an external
USB memory device/USB printer.
13.3 Connecting the PC (USB-B interface (USB Device))
Connect the Multi 3620 IDS to the PC via the USB-B interface.
Installation of the
USB driver on the
PC
System requirements of the PC for installation of the USB driver:
PC with USB port and CD-ROM drive
Microsoft Windows
(for details, see enclosed installation CD, Driver directory)
1 Output the current measurement data to the USB-B interface with .
1 Insert the supplied installation CD in the CD drive of your PC.
2 Install the driver from the CD.
Follow the Windows installation instructions as necessary.
3 Connect the Multi 3620 IDS to the PC via the USB-B interface.
The meter is listed as a virtual COM interface among the connections
in the Windows instrument manager.
4 Set the same transmission data at the connected instrument (PC):
Baud rate: to be selected in the range 1200 ... 19200
Handshake: RTS/CTS
Set at the PC only:
– Parity: none
– Data bits: 8
– Stop bits: 1
