Batteries is turned OFF and removed from the Airframe.
Airframe is cleaned, and chemicals residues are drained.
📋
PREREQUISITE
Disassembling
03 02
01
01
01
02
03
01. Unsecure the System Cables from the cable holder, then disconnect the System cable
connecting the payload system to the Airframe.
02. Disconnect the two liquid tubes from the Peristaltic pumps.
03. Unlock the two Airframe Hasps, then remove the Airframe from the RevoSpray.
📖
INSTRUCTION
