Overview – RevoCast P3
01
Material container cover
06
Material container
02
Boss alignment
07
Quick Assembly unit Hasp
03
Residual sensor
08
Spreader Motor Cable (L)
04
Frame Hook
09
Spreader Motor Cable (R)
05
System cable
10
Spreader Disc
11
Spreader Motor
01 02 03 04 05
06
07
08 09 10 11
