XAG AUSTRALIA
166
maintenance guiDe
Maintenance Cycle – Airframe
Component
Service Schedule
(Recommended)
Service Plan
(Recommended)
Main Fuselage Every 300 ha
Ensure the Main Fuselages are intact, free from cracks or
dents, and that all components are securely attached.
Fuselage Front
Compartment Frame
Every 300 ha
Ensure the Fuselage Front Compartment Frame is intact,
free from cracks, and securely fastened to the main body.
Fuselage Handle Every 300 ha
Ensure the Fuselage Handles are intact, provide a firm
grip, and show no signs of wear or damage.
Fuselage Arm Cover Every 300 ha
Ensure the Fuselage Arm Covers fit snugly, are free from
cracks, and protect the underlying components effectively.
Airframe Arm Clamp Every 300 ha
Ensure the Arm Clamps are intact, provide a secure hold,
and are free from signs of wear or corrosion.
Airframe Arm Every 300 ha
Ensure the Arms are free from damages or deformation.
Confirm that they securely attach and release from the
aircraft body without any hindrance.
Airframe Hasp Every 300 ha
Ensure the Airframe Hasps are intact, securely fastened,
and operate smoothly without jamming.
Airframe Hasp Bracket Every 300 ha
Ensure the Airframe Hasp Brackets are intact, screws are
tightened, and there's no sign of rust or corrosion.
Motor Bracket Every 300 ha
Ensure the Motor Brackets are free from deformations or
damages. Confirm that all connections between the arm
and motor are secure and that there's no play or wobble.
Motor Bracket Pin
Buffer
Monthly
Ensure the Bracket Pin Buffer is in place and shows no
signs of damage or wear.
Motor Bracket Pin Monthly
Ensure the Bracket Pin is in place, securely fastened, and
free from damage or wear.
Tail Frame Beam Every 300 ha
Ensure the Tail Frame Beam is intact, straight, and securely
attached to the main frame.
Tail Frame Every 300 ha
Ensure the Tail Frame is intact, free from cracks, and
securely attached to the main body.
Battery Socket Housing Every 300 ha
Ensure the Battery Socket Housings are intact, provide a
secure fit for the batteries, and show no signs of wear or
damage.
