Note
Trim settings cannot be adjusted to remove less than 2 mm (0.078 in.) or more than 20
mm (0.787 in.) of edge material from the booklet. Adjustments less than 2 mm (0.078
in.) may produce poor trim quality, and adjustments greater 20 mm (0.078 in.) will result
in no trimming to the booklet edge.
Choose the setting that best fits your needs for the booklet output.
Trim Guidelines
The following table shows various scenarios using different paper weights, media types,
and trim setting selections. Use this table as a guideline when selecting a trim setting
for your specific job.
Note
The settings shown in the following table are provided as examples and are not meant
to represent every possible job scenario; again, use this table as a guideline only.
Pages in
Finished
Booklet
Trim Setting
(mm)
Paper Weight
(lbs / gsm)
Finished Booklet
Size
Paper Size
2013020 lbs. (75 gsm)5.5x8.5 in.
(149x210mm)
8.5x11 in./A4
(210x298mm)
1
1412524 lbs. (90 gsm)5.5x8.5 in.
(149x210mm)
8.5x11 in./A4
(210x298mm)
2
1013532 lbs.
(120gsm)
5.5x8.5 in.
(149x210mm)
8.5x11 in./A4
(210x298mm)
3
1012520 lbs. (75 gsm)5.5x8.5 in.
(149x210mm)
8.5x11 in./A4
(210x298mm)
4
1213580 lbs.
(120gsm)
5.5x8.5 in.
(149x210mm)
8.5x11 in./A4
(210x298mm)
5
617220 lbs. (75 gsm)8.5x7 in.
(250x176.5mm)
8.5x14 in./B4
(250x353mm)
6
617024 lbs. (90 gsm)8.5x7 in.
(250x176.5mm)
8.5x14 in./B4
(250x353mm)
7
1420024 lbs. (90 gsm)8.5x11 in./A4
(210x297mm)
11x17 in./A3
(297x420mm)
8
520580 lbs.
(216gsm)
8.5x11 in./A4
(210x297mm)
11x17 in./A3
(297x420mm)
9
2221020 lbs. (80 gsm)8.5x11 in./A4
(210x297mm)
11x17 in./A3
(297x420mm)
10
821024 lbs. (90 gsm)8.5x11 in./A4
(210x297mm)
11x17 in./A3
(297x420mm)
11
14-9Xerox
®
Color C60/C70 Printer
User Guide
SquareFold Trimmer Module
