FreeFlow Process Manager Operator and Administrator Guide
2-93
Workflow Builder
6. Select from the following Sheet Face options:
•[Mark both sides] to place crop marks on the front and
back of sheets. This is the default selection when a duplex
job is defined.
•[Mark front side only] to place crop marks on the front
side of sheets. This is the default selection when a simplex
job is defined.
•[Mark back side only] to place crop marks on the back of
sheets.
7. Select from the following Interval options:
•[Mark every sheet] to apply crop marks to all sheets in the
output.
•[Mark first sheet] to apply crop marks to the first sheet in
the output
•[Mark last sheet] to apply crop marks to the last sheet in
the output.
•[Mark every] to apply crop marks to every “n” sheet as
defined by the user via the sheets spin box. Range: 1 to
500.
–[Starting with the first sheet] to start crop marks on
the first sheet when selected, or on sheet(s) N when
not selected.
8. Select from the following Size and Color options:
•[Crop mark length]: Defines the length of the crop mark
from corner offset outward to the edge of the cell, sheet, or
page.
•[Crop mark color]: Defines the color of the crop mark.
•[Crop mark bleed]: Defines the distance between the crop
marks and the corner of the rectangle the crop marks
identify. For example, if the bleed length is set to “0,” the
horizontal and vertical crop mark lines that form a corner
would meet. Larger values space the lines away from each
other.
9. Select [OK] to accept the changes and close the window.
NOTE: If printing, ensure that the sides imaged and the paper
stock options in the print component are consistent with the
options specified here.
