Print Jobs
MANAGING JOBS
From the control panel Jobs menu, you can view lists of active jobs, secure jobs, or completed jobs. You can pause,
delete, print, or view job progress or job details for a selected job. When you send a secure print job, the job is held
until you release it by typing a passcode at the control panel. For details, refer to Printing Special Job Types
From the Jobs window in the Embedded Web Server, you can view a list of active and saved print jobs.
Pausing, Promoting, or Deleting a Job Waiting to Print
1. At the printer control panel, press the HHoommee button.
2. Touch JJoobbss, then touch the name of the required print job.
3. Select a task.
Note: If you do not make a selection, the job automatically resumes after the set timeout period.
To pause the print job, touch HHoolldd. To resume the print job, touch RReelleeaassee.
To delete the print job, touch DDeelleettee. At the prompt, touch DDeelleettee.
To move the job to the top of the list, touch PPrroommoottee.
To view the status of the job, touch JJoobb PPrrooggrreessss.
To view information about the job, touch JJoobb DDeettaaiillss, then touch JJoobb SSeettttiinnggss or RReeqquuiirreedd RReessoouurrcceess.
4. To return to the Home screen, press the HHoommee button.
Note:
The system administrator can restrict users from deleting jobs. If a system administrator restricts job
deletion, you can view the jobs, but you cannot delete them.
Only the user that sent the job, or the system administrator, can delete a Secure Print job.
Printing a Job Held for Resources
When a job is held for resources, a status message and a pop-up alert appear on the control panel, as default. From
the Embedded Web Server, the system administrator can configure whether only a status message appears or both
status message and a pop-up alert appear on the control panel.
1. If the pop-up alert is disabled by the system administrator, to view the held jobs, do the following:
a. At the printer control panel, press the HHoommee button.
b. Touch JJoobbss.
A list with active jobs, that are queued for the printer, appears.
2. When the pop-up alert is enabled, if a job is held for resources, a pop-up alert appears on the control panel. On
the pop-up alert, touch VViieeww AAccttiivvee JJoobbss.
A list with active jobs, that are queued for the printer, appears.
Xerox
®
VersaLink
®
B415 Multifunction Printer User Guide 169
Printing

Table of Contents

Other manuals for Xerox VersaLink B415

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink B415 and is the answer not in the manual?

Xerox VersaLink B415 Specifications

General IconGeneral
N-up printing2, 4, 6, 8, 9, 16
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Warm-up time (from sleep mode)2.8 s
Time to first page (black, normal)5.4 s
Print speed (black, normal quality, A4/US Letter)47 ppm
USB connectorUSB Type-A / USB Type-B
Optional connectivityWireless LAN
USB 2.0 ports quantity2
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Security algorithms256-bit AES, 802.1x RADIUS, FIPS 140, HTTPS, IPSec, SHA-256, SNMP, SNMPv2, SNMPv3, TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Mopria Print Service, Xerox PrintBack
Storage mediaeMMC
Internal memory2048 MB
Processor cores4
Internal storage capacity32 GB
Sound power level (standby)31 dB
Sound power level (printing)71 dB
Sound pressure level (standby)14 dB
Sound pressure level (printing)55 dB
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Maximum number of copies9999 copies
Time to first copy (black, normal)5.3 s
DisplayLCD
Control typeButtons, Touch
Product colorGrey, White
Display diagonal7 \
Market positioningBusiness
AC input voltage220 - 240 V
AC input frequency50/60 Hz
Power consumption (sleep)1.6 W
Power consumption (standby)17 W
Scan toE-mail, FTP, HTTP, Network folder, SMB, TWAIN, USB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Maximum scan area216 x 356 mm
Output color depth24 bit
Output grayscale depth8 bit
Image formats supportedJPEG, TIFF
Document formats supportedPDF
Mac operating systems supportedMac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Mobile operating systems supportedAndroid, iOS
Server operating systems supportedWindows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supportedWindows 10, Windows 11, Windows 8.1
Operating temperature (T-T)10 - 32.2 °C
Operating relative humidity (H-H)15 - 80 %
FaxingMono faxing
Modem speed33.6 Kbit/s
Fax coding methodsJBIG, MH, MMR (Fax coding method), MR
Package depth584 mm
Package width559 mm
Package height659 mm
Package weight25600 g
PCL fonts93
Printer fontsPCL, PostScript
Printing colorsBlack
Duplex functionsCopy, Print
Country of originChina
Maximum duty cycle175000 pages per month
Number of PostScript fonts173
Number of print cartridges1
Page description languagesPCL 5c, PCL 6, PDF, PostScript 3
Cables includedAC
Included cartridge capacity (CMY)2000 pages
Included cartridge capacity (black)2400 pages
Total input capacity650 sheets
Total output capacity250 sheets
Paper tray 1 input capacity550 sheets
Auto document feeder (ADF) input capacity100 sheets
Custom media width76 - 216 mm
Custom media length148 - 356 mm
Paper tray media typesBond paper, Card stock, Envelopes, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Rough paper
Paper tray media weight60 - 216 g/m²
ISO A-series sizes (A0...A9)A4, A5
Maximum ISO A-series paper sizeA4
Auto Document Feeder (ADF) media weight52 - 120 g/m²
Current rating3.7 A
Number of users5000 user(s)
Languages supportMulti
Weight and Dimensions IconWeight and Dimensions
Depth452 mm
Width479 mm
Height514 mm
