3. Close the document feeder top cover.
Paper Tray Jams
If a jam occurs in the paper tray areas, a message appears to indicate the areas or paper tray that requires clearing.
To clear the jam, follow the instructions on the touch screen to locate the jammed paper, then clear the jam. When
removing jammed paper from the device, remove the paper in the direction it was feeding, and take care not to
leave any remnants of paper in the device.
After the paper tray jam has been cleared, the device continues printing the job from where the job stopped.
If further paper tray jams are experienced, try to load fresh paper in the paper tray. The paper could have excessive
curl, excessive moisture, or be damaged.
For more information about paper jam causes and potential solutions, refer to Paper Misfeeds and Paper Size Jams.
Clearing Jams at Standard Trays 1–4
To clear the paper jams at Standard Trays 1–4:
1. Before you remove any tray from the printer, view the paper jam message on the control panel. Remove the
jam that is shown on the control panel, then remove other paper jams.
2. Pull out the tray until it stops.
Xerox
®
VersaLink
®
B415 Multifunction Printer User Guide 245
Troubleshooting

Xerox VersaLink B415 Specifications

General

N-up printing	2, 4, 6, 8, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	2.8 s
Time to first page (black, normal)	5.4 s
Print speed (black, normal quality, A4/US Letter)	47 ppm
USB connector	USB Type-A / USB Type-B
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, 802.1x RADIUS, FIPS 140, HTTPS, IPSec, SHA-256, SNMP, SNMPv2, SNMPv3, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service, Xerox PrintBack
Storage media	eMMC
Internal memory	2048 MB
Processor cores	4
Internal storage capacity	32 GB
Sound power level (standby)	31 dB
Sound power level (printing)	71 dB
Sound pressure level (standby)	14 dB
Sound pressure level (printing)	55 dB
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	9999 copies
Time to first copy (black, normal)	5.3 s
Display	LCD
Control type	Buttons, Touch
Product color	Grey, White
Display diagonal	7 \
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Power consumption (sleep)	1.6 W
Power consumption (standby)	17 W
Scan to	E-mail, FTP, HTTP, Network folder, SMB, TWAIN, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Mobile operating systems supported	Android, iOS
Server operating systems supported	Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supported	Windows 10, Windows 11, Windows 8.1
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	15 - 80 %
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Package depth	584 mm
Package width	559 mm
Package height	659 mm
Package weight	25600 g
PCL fonts	93
Printer fonts	PCL, PostScript
Printing colors	Black
Duplex functions	Copy, Print
Country of origin	China
Maximum duty cycle	175000 pages per month
Number of PostScript fonts	173
Number of print cartridges	1
Page description languages	PCL 5c, PCL 6, PDF, PostScript 3
Cables included	AC
Included cartridge capacity (CMY)	2000 pages
Included cartridge capacity (black)	2400 pages
Total input capacity	650 sheets
Total output capacity	250 sheets
Paper tray 1 input capacity	550 sheets
Auto document feeder (ADF) input capacity	100 sheets
Custom media width	76 - 216 mm
Custom media length	148 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Rough paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 120 g/m²
Current rating	3.7 A
Number of users	5000 user(s)
Languages support	Multi

Weight and Dimensions

Depth	452 mm
Width	479 mm
Height	514 mm
