Supply Status
You can check the status and percentage of life remaining for your printer supplies at the control panel or from the
Embedded Web Server. When printer supplies near their replacement time, warning alerts appear at the control
panel.
You can customize the alerts that appear at the control panel and configure email alert notifications using the
Embedded Web Server.
To check the supplies status and set up alerts using the Embedded Web Server, refer to the System Administrator
Guide at www.xerox.com/office/VLB415docs.
To check the supplies status at the control panel:
1. At the printer control panel, press the HHoommee button.
2. To view status information for the printer supplies, touch DDeevviiccee >> SSuupppplliieess.
3. To view details about a specific supply item, touch the item required.
4. To return to the Supplies screen, touch XX.
5. To view more details, touch OOtthheerr SSuupppplliieess. Scroll through the list, then select an option.
6. To return to the Supplies screen, touch XX.
7. To print the Supplies Report, touch PPrriinntt SSuupppplliieess RReeppoorrtt.
8. To return to the Device screen, touch XX.
TONER CARTRIDGES
CCaauuttiioonn::
When replacing a toner cartridge, be careful not to spill the toner. If any toner spills, avoid contact with
clothes, skin, eyes, and mouth. Do not inhale the toner dust.
Keep toner cartridges out of the reach of children. If a child accidentally swallows toner, have the child
spit out the toner, and rinse out their mouth with water. Consult a physician immediately.
CCaauuttiioonn:: Use a damp cloth to wipe off spilled toner. Never use a vacuum cleaner to remove spills. Electric
sparks inside the vacuum cleaner can cause a fire or explosion. If you spill a large volume of toner, contact
your local Xerox representative.
CCaauuttiioonn:: Never throw a toner cartridge into an open flame. Remaining toner in the cartridge can catch
fire and cause burn injuries or an explosion.
222
Xerox
®
VersaLink
®
B415 Multifunction Printer User Guide
Maintenance

Table of Contents

Other manuals for Xerox VersaLink B415

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink B415 and is the answer not in the manual?

Xerox VersaLink B415 Specifications

General IconGeneral
N-up printing2, 4, 6, 8, 9, 16
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Warm-up time (from sleep mode)2.8 s
Time to first page (black, normal)5.4 s
Print speed (black, normal quality, A4/US Letter)47 ppm
USB connectorUSB Type-A / USB Type-B
Optional connectivityWireless LAN
USB 2.0 ports quantity2
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Security algorithms256-bit AES, 802.1x RADIUS, FIPS 140, HTTPS, IPSec, SHA-256, SNMP, SNMPv2, SNMPv3, TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Mopria Print Service, Xerox PrintBack
Storage mediaeMMC
Internal memory2048 MB
Processor cores4
Internal storage capacity32 GB
Sound power level (standby)31 dB
Sound power level (printing)71 dB
Sound pressure level (standby)14 dB
Sound pressure level (printing)55 dB
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Maximum number of copies9999 copies
Time to first copy (black, normal)5.3 s
DisplayLCD
Control typeButtons, Touch
Product colorGrey, White
Display diagonal7 \
Market positioningBusiness
AC input voltage220 - 240 V
AC input frequency50/60 Hz
Power consumption (sleep)1.6 W
Power consumption (standby)17 W
Scan toE-mail, FTP, HTTP, Network folder, SMB, TWAIN, USB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Maximum scan area216 x 356 mm
Output color depth24 bit
Output grayscale depth8 bit
Image formats supportedJPEG, TIFF
Document formats supportedPDF
Mac operating systems supportedMac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Mobile operating systems supportedAndroid, iOS
Server operating systems supportedWindows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supportedWindows 10, Windows 11, Windows 8.1
Operating temperature (T-T)10 - 32.2 °C
Operating relative humidity (H-H)15 - 80 %
FaxingMono faxing
Modem speed33.6 Kbit/s
Fax coding methodsJBIG, MH, MMR (Fax coding method), MR
Package depth584 mm
Package width559 mm
Package height659 mm
Package weight25600 g
PCL fonts93
Printer fontsPCL, PostScript
Printing colorsBlack
Duplex functionsCopy, Print
Country of originChina
Maximum duty cycle175000 pages per month
Number of PostScript fonts173
Number of print cartridges1
Page description languagesPCL 5c, PCL 6, PDF, PostScript 3
Cables includedAC
Included cartridge capacity (CMY)2000 pages
Included cartridge capacity (black)2400 pages
Total input capacity650 sheets
Total output capacity250 sheets
Paper tray 1 input capacity550 sheets
Auto document feeder (ADF) input capacity100 sheets
Custom media width76 - 216 mm
Custom media length148 - 356 mm
Paper tray media typesBond paper, Card stock, Envelopes, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Rough paper
Paper tray media weight60 - 216 g/m²
ISO A-series sizes (A0...A9)A4, A5
Maximum ISO A-series paper sizeA4
Auto Document Feeder (ADF) media weight52 - 120 g/m²
Current rating3.7 A
Number of users5000 user(s)
Languages supportMulti
Weight and Dimensions IconWeight and Dimensions
Depth452 mm
Width479 mm
Height514 mm
