Xerox VersaLink B415 User Manual

Device
DEVICE OVERVIEW
The Device App gives you access to information about your printer, including the serial
number and model. You can view the status of the paper trays, billing and supplies
information, and print information pages.
Many Device options can be configured to meet your individual needs. For details about configuring all of the
Device settings, refer to the System Administrator Guide at www.xerox.com/office/VLB415docs.
Device Options
The following device options are available:
OOPPTTIIOONN DDEESSCCRRIIPPTTIIOONN
Admin
Personalization
Settings
For logged-in users, Personalization Settings provides access to the
PPeerrssoonnaalliizzeedd LLaanngguuaaggee and MMaannaaggee SSuuggggeessttiioonnss options. For
more information about Personalization settings, refer to Personalize.
Language Pressing the Language button allows you to set the language that
appears on the control panel touch screen.
Note: Sometimes this option is hidden from view. For details,
refer to System Administrator Guide at www.xerox.com/office/
VLB415docs.
Accessibility Pressing Accessibility allows you to access the IInnvveerrtt DDiissppllaayy CCoolloorr
feature, that changes the appearance of the control panel touch
screen. For more information, refer to Accessibility.
About The About option provides an overview of your device, the device
serial number, and information about current settings.
Information
Pages
Your printer has a set of information pages that you can print. These
pages include configuration and font information, demonstration
pages, and more.
Notifications Use the Notifications option to see details of any current alerts or
errors on the device. A Fault History option displays fault codes and
the date that they occurred on the device.
Paper Trays Use the Paper Trays option to see the paper size, type, and color set
for each paper tray and the tray-capacity status.
Supplies Use the Supplies section to monitor the status of the components you
can replace. The supply level and estimated number of impressions or
days that remain for each unit are displayed.
Xerox
®
VersaLink
®
B415 Multifunction Printer User Guide 91
Xerox
®
Apps

Xerox VersaLink B415 Specifications

General

N-up printing	2, 4, 6, 8, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	2.8 s
Time to first page (black, normal)	5.4 s
Print speed (black, normal quality, A4/US Letter)	47 ppm
USB connector	USB Type-A / USB Type-B
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, 802.1x RADIUS, FIPS 140, HTTPS, IPSec, SHA-256, SNMP, SNMPv2, SNMPv3, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service, Xerox PrintBack
Storage media	eMMC
Internal memory	2048 MB
Processor cores	4
Internal storage capacity	32 GB
Sound power level (standby)	31 dB
Sound power level (printing)	71 dB
Sound pressure level (standby)	14 dB
Sound pressure level (printing)	55 dB
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	9999 copies
Time to first copy (black, normal)	5.3 s
Display	LCD
Control type	Buttons, Touch
Product color	Grey, White
Display diagonal	7 \
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Power consumption (sleep)	1.6 W
Power consumption (standby)	17 W
Scan to	E-mail, FTP, HTTP, Network folder, SMB, TWAIN, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Mobile operating systems supported	Android, iOS
Server operating systems supported	Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supported	Windows 10, Windows 11, Windows 8.1
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	15 - 80 %
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Package depth	584 mm
Package width	559 mm
Package height	659 mm
Package weight	25600 g
PCL fonts	93
Printer fonts	PCL, PostScript
Printing colors	Black
Duplex functions	Copy, Print
Country of origin	China
Maximum duty cycle	175000 pages per month
Number of PostScript fonts	173
Number of print cartridges	1
Page description languages	PCL 5c, PCL 6, PDF, PostScript 3
Cables included	AC
Included cartridge capacity (CMY)	2000 pages
Included cartridge capacity (black)	2400 pages
Total input capacity	650 sheets
Total output capacity	250 sheets
Paper tray 1 input capacity	550 sheets
Auto document feeder (ADF) input capacity	100 sheets
Custom media width	76 - 216 mm
Custom media length	148 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Rough paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 120 g/m²
Current rating	3.7 A
Number of users	5000 user(s)
Languages support	Multi

Weight and Dimensions

Depth	452 mm
Width	479 mm
Height	514 mm
