Xerox VersaLink B415 - Label and Envelope Misfeeds

Label and Envelope Misfeeds
PPRROOBBAABBLLEE CCAAUUSSEESS SSOOLLUUTTIIOONNSS
The label sheet is facing the wrong way in the tray. Load label sheets according to the instructions from
the manufacturer.
Load labels face down with the bottom edge to the
front of the tray in standard Trays 1–4.
Load labels face up with the bottom edge toward the
feed direction of the tray in Bypass Tray.
For loading labels with correct orientation, refer to
Labels.
Envelopes are loaded incorrectly or in the wrong tray. Use Bypass Tray to print envelopes.
Note: Envelopes are supported only in Bypass
Tray.
For loading envelopes with correct orientation, refer to
Envelopes.
Envelopes are loaded incorrectly in Bypass Tray. To load envelopes in Bypass Tray:
• For envelopes with the flap on a long edge, load
envelopes with the flaps face down and closed.
Keep the flaps toward the left.
• For envelopes with the flap on a short edge, load
envelopes with the flaps face down and closed.
Insert the envelopes with the flaps toward the feed
direction.
• For the custom-size envelopes, when the flap is on
the short edge and the long edge is longer than
216 mm (8.5 in.), load envelopes with the flaps
face down and closed. Insert the envelope with the
flap toward the feed direction. For custom-size
envelopes, define the custom size on the control
panel.
Note: Unless the long edge is longer than 216
mm (8.5 in.) or the short edge is less than the
minimum width of the feeder, the flap of the
envelop should always be to the left.
