For more information about all the Personalization options, see Personalize.
Note: To allow the logged-in user to personalize their local user interface experience, the System
Administrator is required to configure the device personalization policy. For information on configuring the
device policy to enable user personalization, refer to the System Administrator Guide at www.xerox.com/
office/VLB415docs.
ACCOUNTING
Accounting is used to track and record the numbers of Copy, Print, Scanning, Server Fax, and Fax jobs that the
device produces for each user. The system administrator is required to create user accounts and enable the
accounting feature. After Accounting is enabled, provide Accounting IDs at the printer to access restricted apps. If
Authentication is enabled, you are required to log in first. Before you print documents from a computer, provide
your account details in the print driver.
The system administrator can set limits to restrict the total number of jobs by type that a user can send to the
printer. The administrator can generate reports that list usage data for individual users and groups.
For details, refer to the System Administrator Guide at www.xerox.com/office/VLB415docs.
LOGGING IN
Logging in is the process by which you identify yourself to the printer for authentication. If authentication is set, to
access printer features, you log in with your user credentials.
Logging In at the Control Panel
Note:
Before logging in for the first time at the Xerox device control panel, log in to the Embedded Web Server,
then update your password. For details, refer to Logging In Using the Embedded Web Server.
If you do not know your user name or password, contact your system administrator.
1. At the printer control panel, press the HHoommee button.
2. Touch LLoogg IInn.
3. For User Name, use the keypad and enter your name, then touch NNeexxtt.
4. If prompted, enter the password, then touch DDoonnee.
Note: To access each app that is password-protected, repeat steps 3 and 4.
Xerox
®
VersaLink
®
B415 Multifunction Printer User Guide 43
Getting Started

Table of Contents

Other manuals for Xerox VersaLink B415

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink B415 and is the answer not in the manual?

Xerox VersaLink B415 Specifications

General IconGeneral
N-up printing2, 4, 6, 8, 9, 16
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Warm-up time (from sleep mode)2.8 s
Time to first page (black, normal)5.4 s
Print speed (black, normal quality, A4/US Letter)47 ppm
USB connectorUSB Type-A / USB Type-B
Optional connectivityWireless LAN
USB 2.0 ports quantity2
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Security algorithms256-bit AES, 802.1x RADIUS, FIPS 140, HTTPS, IPSec, SHA-256, SNMP, SNMPv2, SNMPv3, TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Mopria Print Service, Xerox PrintBack
Storage mediaeMMC
Internal memory2048 MB
Processor cores4
Internal storage capacity32 GB
Sound power level (standby)31 dB
Sound power level (printing)71 dB
Sound pressure level (standby)14 dB
Sound pressure level (printing)55 dB
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Maximum number of copies9999 copies
Time to first copy (black, normal)5.3 s
DisplayLCD
Control typeButtons, Touch
Product colorGrey, White
Display diagonal7 \
Market positioningBusiness
AC input voltage220 - 240 V
AC input frequency50/60 Hz
Power consumption (sleep)1.6 W
Power consumption (standby)17 W
Scan toE-mail, FTP, HTTP, Network folder, SMB, TWAIN, USB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Maximum scan area216 x 356 mm
Output color depth24 bit
Output grayscale depth8 bit
Image formats supportedJPEG, TIFF
Document formats supportedPDF
Mac operating systems supportedMac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Mobile operating systems supportedAndroid, iOS
Server operating systems supportedWindows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022
Windows operating systems supportedWindows 10, Windows 11, Windows 8.1
Operating temperature (T-T)10 - 32.2 °C
Operating relative humidity (H-H)15 - 80 %
FaxingMono faxing
Modem speed33.6 Kbit/s
Fax coding methodsJBIG, MH, MMR (Fax coding method), MR
Package depth584 mm
Package width559 mm
Package height659 mm
Package weight25600 g
PCL fonts93
Printer fontsPCL, PostScript
Printing colorsBlack
Duplex functionsCopy, Print
Country of originChina
Maximum duty cycle175000 pages per month
Number of PostScript fonts173
Number of print cartridges1
Page description languagesPCL 5c, PCL 6, PDF, PostScript 3
Cables includedAC
Included cartridge capacity (CMY)2000 pages
Included cartridge capacity (black)2400 pages
Total input capacity650 sheets
Total output capacity250 sheets
Paper tray 1 input capacity550 sheets
Auto document feeder (ADF) input capacity100 sheets
Custom media width76 - 216 mm
Custom media length148 - 356 mm
Paper tray media typesBond paper, Card stock, Envelopes, Glossy paper, Heavy paper, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Rough paper
Paper tray media weight60 - 216 g/m²
ISO A-series sizes (A0...A9)A4, A5
Maximum ISO A-series paper sizeA4
Auto Document Feeder (ADF) media weight52 - 120 g/m²
Current rating3.7 A
Number of users5000 user(s)
Languages supportMulti
Weight and Dimensions IconWeight and Dimensions
Depth452 mm
Width479 mm
Height514 mm
