Spare Parts List
Workcentre PE 220 11/05 5-13
PL 6 Paper Path Assembly
Item Part Number Description Qt’y Remark
0 PAPER-PATH ASSEM 1
1 038N00463 GUIDE-M-PAPER PATH 1
2 130N01408 LEVER-ACTUATOR FEED SENSOR 1
3 009N01519 SPRING ETC-LEVER SENSOR 1
4 015N00558 IPR-PLATE SAW 1
5 NOT USED
6 GROUND-P-ZENER 1
7 GROUND-P-THV 1
8 GROUND-P-SAW 1
9 019N00841 MEA UNIT-HOLDER_PAD 1
9-1 009N01520 SPRING ETC-EXIT ROLL FD 2
9-2 019N00836 PAD-FRICTION 1
9-3 019N00837 HOLDER-M-PAD 1
10 LEVER-M-KICKER P/U 2
11 130N01419 MEA UNIT-PICK UP GEAR 1
11-1 GEAR-PICK_UP B 1
11-2 GEAR-PICK_UP A 1
11-3 SPRING-CS 3
12 121N01078 SOLENOID-MP_R2 3
13 007N01375 GEAR-FEED 35/19 3
14 016N00261 BUSH-M-TR L 1
15 016N00281 PMO-BUSHING_TR(L) 1
16 009N01521 SPRING ETC-TR(12) 2
17 022N02126 ROLLER-TRANSFER 1
18 019N00838 HOLDER-PTL 1
19 IPR-P-EARTH TRANSFER 1
20 SHAFT-P-PICK_UP 1
21 130N01424 MEA UNIT PICK_UP 1
21-1 HOUSING-M-PICK_UP B 1
21-2 HOUSING-M-PICK_U 1
21-3 130N01416 RUBBER-PICK_UP 1
22 130N01410 CAM-M-PICK_UP 2
23 007N01376 GEAR-TRANSFER 1
24 BRACKET-P-BAR_PICK_UP 1
To Next Page
