Status Indicator RAPs
2-24 11/05 Workcentre PE 220
16 Abnormal Noise RAP
Description
There is noise from the ADF when copying.
Check and Cause Solution
1. Check the Scanner Motor, gearbox and
rollers.
1. Check for correct assembly of gears and
motor. Ensure no parts are damaged and
there are no foreign objects in the mechanism
or scan path. Replace any worn parts, PL 2.
2. Check the Motor Driver on Driver PBA. 2. Replace the Main PBA, PL 1 and ADF
PBA, PL 2.
