Spare Parts List
Workcentre PE 220 11/05 5-7
PL 3 Platen Cover Assembly
Item Part Number Description Qt’y Remark
0 002N02448 MEA-COVER PLATEN 1
1 002N02436 COVER-M-PLATEN 1
2 095N00274 SHEET-WHITE SPONGE 1
3 038N00405 PMO-TX STACKER 1
4 38N00410 PMO-DOC GUIDE(R) 1
5 38N00406 PMO-DOC GUIDE(L) 1
6 028N00321 IPR-WASHER SPRING CU 2
7 007N01178 GEAR-PINION 1
8 009N01514 SPRING ETC-FEED 6
9 SHAFT PINCH 1
10 022N02014 PMO-ROLL PINCH 2
11 SHAFT-IDLE FEED 2
12 022N02019 RPR-ROLLER EXIT IDLE 2
13 050N00479 MEA-TX STACKER 1
To Next Page
