7 Series FPGAs GTP Transceivers User Guide www.xilinx.com 117
UG482 (v1.9) December 19, 2016
TX Configurable Driver
TXPOSTCURSOR[4:0] In Async Transmitter post-cursor TX pre-emphasis control. The default is user
specified. All listed values (dB) are typical.
TXPOSTCURSORINV In Async When set to 1'b1, inverts the polarity of the TXPOSTCURSOR
coefficient. The default is 1'b0.
Table 3-28: TX Configurable Driver Ports (Cont’d)
Port Dir Clock Domain Description
[4:0] Emphasis (dB) Coefficient Units
5'b00000 0.00 0
5'b00001 0.22 1
5'b00010 0.45 2
5'b00011 0.68 3
5'b00100 0.92 4
5'b00101 1.16 5
5'b00110 1.41 6
5'b00111 1.67 7
5'b01000 1.94 8
5'b01001 2.21 9
5'b01010 2.50 10
5'b01011 2.79 11
5'b01100 3.10 12
5'b01101 3.41 13
5'b01110 3.74 14
5'b01111 4.08 15
5'b10000 4.44 16
5'b10001 4.81 17
5'b10010 5.19 18
5'b10011 5.60 19
5'b10100 6.02 20
5'b10101 6.47 21
5'b10110 6.94 22
5'b10111 7.43 23
5'b11000 7.96 24
5'b11001 8.52 25
5'b11010 9.12 26
5'b11011 9.76 27
5'b11100 10.46 28
5'b11101 11.21 29
5'b11110 12.04 30
5'b11111 12.96 31
